Plug and Play Jack Plate
The Plug and Play Jack Plate is a complete drop-in assembly for stereo speaker cabinets. The standard version shown below is marked for the 8 Ohm Stereo and 4/16 Ohm Mono. This is a common setup with guitar cabinets. What is uncommon is the elimination of the switch. This makes connecting the amplifier to the cabinet super easy.
This jackplate is designed and printed for four (4) speakers of 16 ohms each, or two (2) speakers of 8 ohms each. If you are using four 8 ohm speakers, the resulting ohm loads will be half of what is printed on the plate. If you are using two 16 ohm speakers, the resulting ohm loads will be double what is printed on the plate.
Wiring Diagrams and Impedance charts can be found under the documentation tab.
Original: $29.00
-65%$29.00
$10.15
Description
The Plug and Play Jack Plate is a complete drop-in assembly for stereo speaker cabinets. The standard version shown below is marked for the 8 Ohm Stereo and 4/16 Ohm Mono. This is a common setup with guitar cabinets. What is uncommon is the elimination of the switch. This makes connecting the amplifier to the cabinet super easy.
This jackplate is designed and printed for four (4) speakers of 16 ohms each, or two (2) speakers of 8 ohms each. If you are using four 8 ohm speakers, the resulting ohm loads will be half of what is printed on the plate. If you are using two 16 ohm speakers, the resulting ohm loads will be double what is printed on the plate.
Wiring Diagrams and Impedance charts can be found under the documentation tab.
